SRU6-B60 4P 60kA Surge Protective Device SPD


$5.94

  • SKU: ZH04
  • Availability: 999
Total $5.94
WhatsApp
If the price of the product is reduced within 30 days, we will notify you via email, SMS and mobile client~
Notify you when the item is below the price
Mobile phone number
Email address
If the goods arrive within 30 days, we will notify you via email, SMS and mobile client~
Mobile phone number
Email address
Origin China
Material Flame-retardant PA66 housing + Silver alloy contacts + Copper conductor + Metal Oxide Varistor (MOV) chip + High-energy graphite gap
Product Name SRU6-B60 4P 60kA Surge Protective Device Mid-Class B SPD
Structure / Process Modular DIN-rail mounting / 4P multi-pole / MOV + GDT series / Built-in thermal disconnection / Failure indication window
Product Features Uc 385V high withstand / In 30kA nominal discharge / Imax 60kA max discharge / Up≤2.0kV voltage protection level / Failure indication window / 35mm standard rail
Type Class B Surge Protective Device (SPD Class I+II) / 4P / Voltage-limiting type mid-spec
Color Off-white flame-retardant housing (Standard color, customizable)
Function Medium lightning direct strike overvoltage protection / Mid-spec Class B lightning protection / Industrial secondary distribution lightning protection / General commercial equipment protection
Application Scenario Small and medium industrial plant main distribution / Commercial building secondary distribution / Hospital / School distribution system / Medium telecom base station
Specification Uc 385V / In 30kA (8/20μs) / Imax 60kA (8/20μs) / Up≤2.0kV / 4P / 35mm DIN rail
Brand OEM/ODM (Customizable)
MOQ 100 pieces
Port Qingdao, Rizhao
