SYWV(Y)-75-5 Physical Foamed Coaxial Cable


$0.36

Xinyuwang Wire & Cable

中国 山东省


  • SKU: XW02
  • Availability: 999
Total $0.36
WhatsApp
If the price of the product is reduced within 30 days, we will notify you via email, SMS and mobile client~
Notify you when the item is below the price
Mobile phone number
Email address
If the goods arrive within 30 days, we will notify you via email, SMS and mobile client~
Mobile phone number
Email address
Origin China
Material Copper-clad steel / oxygen-free copper core, physically foamed PE insulation, PVC sheath
Product Name SYWV(Y)-75-5 Physical Foamed Coaxial Cable
Model SYWV(Y)-75-5
Structure / Process Inner conductor + physically foamed PE insulation + aluminum foil shield + braided shield + PVC outer sheath
Characteristic Impedance 75 Ω
Inner Conductor Diameter Approx. 1.0 mm
Sheath Color White, blue, red (transparent), etc.
Shielding Structure Aluminum foil longitudinal wrapping + braided shield
Operating Frequency 5-1000 MHz
Attenuation Meets CATV / broadcasting transmission requirements
Product Features Low loss, low VSWR, excellent anti-interference and stable signal transmission
Type Physical-foamed coaxial cable
Function For CATV, satellite TV, surveillance systems and RF signal transmission
Application Scenario CATV networks, satellite reception, closed-circuit television monitoring and building wiring
Operating Temperature -15 °C to +70 °C
Executive Standard GB/T 14864
Packaging 100 m per roll, or customized as required
